Ignition Coils


Ignition Coil C75

  • Max. 35 kV
  • Max. 75 mJ
  • Max. 8.0 kV/µs
  • Especially developed for GDI engines
  • Max. 15,000 1/min

Ignition Coil C75-E8

  • Max. 35 kV
  • Max. 75 mJ
  • Max. 8.0 kV/µs
  • Especially developed for GDI engines
  • Max. 15,000 1/min

Ignition Coil C90i-E8

  • Max. 40 kV
  • Max. 90 mJ
  • Max. 5.0 kV/µs
  • Fits to spark plugs with a ceramic diameter of 8 mm
  • Max. 15,000 1/min

Ignition Coil C90i-E10

  • Max. 40 kV
  • Max. 90 mJ
  • Max. 5.0 kV/µs
  • Fits to spark plugs with a ceramic diameter of 10 mm
  • Max. 15,000 1/min

Ignition Coil C90i-pro

  • Max. 40 kV
  • Max. 90 mJ
  • Max. 5.0 kV/µs
  • Especially developed for Turbo-GDI engines
  • Max. 15,000 1/min

Ignition Coil C90i-pro evo

  • Max. 40 kV
  • Max. 90 mJ
  • Boosted spark current
  • Especially for engines with high gas turbulences
  • Max. 15,000 1/min

Ignition Coil C90i-WG

  • Max. 35 kV
  • Max. 90 mJ
  • Especially developed for Turbo-GDI engines
  • Max. 15,000 1/min
  • Connection for high voltage wire

Ignition Coil P50/P50-M

  • Max. 35 kV
  • Max. 50 mJ
  • Max. 3.0 kV/µs
  • High voltage contacting via high voltage wire and spark plug connector possible
  • Max. 10,000 1/min

Ignition Coil P65

  • Max. 35 kV
  • Max. 65 mJ
  • Developed for GDI engines
  • Max. 10,000 1/min

Ignition Coil P65-T

  • Max. 33 kV
  • Max. 65 mJ
  • Developed for GDI engines
  • Max. 10,000 1/min (with reduced dwell time)

Ignition Coil P65-TWG

  • Max. 33 kV
  • Max. 65 mJ
  • Developed for GDI engines
  • Max. 10,000 1/min (with reduced dwell time)
  • Connection for high voltage wire

Ignition Coil P65-WG

  • Connection for 30 kV high voltage wire with locking pin (European standard)
  • Max. 35 kV
  • Max. 65 mJ
  • Developed for GDI engines
  • Max. 10,000 1/min

Ignition Coil P65-WS

  • Connection for high voltage wire according to SAE (American standard)
  • Max. 35 kV
  • Max. 65 mJ
  • Developed for GDI engines
  • Max. 10,000 1/min

Ignition Coil PS-T

  • Max. 27 kV
  • Max. 42 mJ
  • Max. 1.5 kV/µs
  • Max. 10,000 1/min
