Display DDU 11

The display DDU 11 integrates a programmable full colour dashboard display with a data logging system for motorsport applications. Additional input devices can be connected via Ethernet, CAN buses, and RS 232.

A basic logging function of 100 channels with recording rate of 20 Hz (50 ms) (4 GB) is always included. The logger can be upgraded to full logging performance (max. 1 kHz (1 ms)). In addition, a 2nd logging partition of 4 GB can be activated. An optional external GPS Sensor keeps track of position on the racetrack.

With the DDU 11, a library of graphical elements for the individual design of display pages and a state-of-the-art user interface menu is available. For quick data transfer from the car, e.g., during pit stop, data logging to a USB stick is available as an option.

Downloads

Features

  • Features user interface menu
  • Features display element design generator
  • 8 top-LEDs and 5 side-LEDs on both sides
  • Supports GPS laptrigger, pre-dated lap time etc.
  • Page change based on events possible

Application

Display

6.5” graphic color display

48 user configurable pages (12 pages organized in 4 switchable page sets)

Resolution

800 x 480 pixel

Supported image file formats

PNG, BMP, JPG, GIF

Processor

667 MHz Dual Core

AD-Converters

10 kHz sampling rate with digital downsampling filter

Real time clock supply

Ultracap™, sustains realtime for 2 weeks

Configurable math channels



User configurable CAN in/out messages

Up to 256 IDs (128 in and out)

Sampling rate

20 Hz (50 ms) standard,
max. 1 kHz (1 ms) as optional upgrade (FULL_LOG_1/FULL_LOG_2)

Online data compression



Internal logger

  • 4 GB memory on partition 1 enabled
  • 100 channels enabled
  • 50 ms Sampling rate enabled
  • FULL_LOG_1 (1,500 channels/1 kHz sampling rate on partition 1) optional
  • FULL_LOG_2 (4 GB memory on partition 2) optional

Logging rates

  • Usage of all features: 600 kB/s
  • Primary logging use case: >800 kB/s
  • Logging data download rate: up to 6.2 MB/s

Ambient light sensor





Technical Specifications

Mechanical Data

Size

203 x 128 x 38.5 mm

Weight

649 g

Protection classification

IP67

Operating temperature internal

-20 to 85°C

Max. vibration

Vibration profile 1 (see Downloads or bosch-motorsport.com)

Electrical Data

Supply voltage

6 to 18 V

Current consumption (w/o sensor supply)

<2 A (at 12 V)

Inputs (option)

4 x analog In (5 V/12 bit), Digital In, Wheelspeed HALL, or Wheelspeed DF11

1 x analog In (5 V/12 bit), Digital In or Laptrigger In

Switchable 3.01 kOhm pull-up resistors for all analog inputs

Sensor Supplies and Screens

1 x Sensor supply 5 V +/- 1 % or UBAT switched (max. 250 mA)

1 x Sensor ground

Connectors and Wires

Mating Connector: TE Connectivity 3-1437290-7

Connector Pins: TE Connectivity 3-1447221-4

Pin Configuration

Pin

Name

Status

1

KL30_KL15/UBAT

Incl.

2

SENSGND

Incl.

3

SENSPWR (5 V or UBAT switched)

Incl.

4

SIG2_IN (Analog In, Digital In, Wheelspeed HALL, Wheelspeed DF11, switchable Pull-Up 3.01 k)

Opt.

5

SIG4_IN (Analog In, Digital In, Wheelspeed HALL, Wheelspeed DF11, switchable Pull-Up 3.01 k)

Opt.

6

USB_GND

Opt.

7

USB_PWR

Opt.

8

KL31/GND

Incl.

9

SIG5_IN_LAPTRG (Analog In, Digital In, switchable Pull-Up 3.01 k)

Opt.

10

SIG1_IN (Analog In, Digital In, Wheelspeed HALL, Wheelspeed DF11, switchable Pull-Up 3.01 k)

Opt.

11

SIG3_IN (Analog In, Digital In, Wheelspeed HALL, Wheelspeed DF11, switchable Pull-Up 3.01 k)

Opt.

12

USB_DN

Opt.

13

USB_DP

Opt.

14

CAN_2_H_RS232_TX (switchable CAN or RS232)

Opt.

15

CAN_1_H

Incl.

16

ETH_CHANNEL0_TXN (Ethernet 100BaseTX)

Incl.

17

ETH_CHANNEL0_TXP

Incl.

18

ETH_CHANNEL0_RXN

Incl.

19

ETH_CHANNEL0_RXP

Incl.

20

TIMESTMP_INOUT (Timesync)

Incl.

21

CAN_2_L_RS232_RX (switchable CAN or RS232)

Opt.

22

CAN_1_L

Incl.

23

ETH_CHANNEL1_TXN (Ethernet 100BaseTX)

Incl.

24

ETH_CHANNEL1_TXP

Incl.

25

ETH_CHANNEL1_RXN

Incl.

26

ETH_CHANNEL1_RXP

Incl.

Communication

CAN interfaces

1

2nd CAN interface or RS232 with IO_EXTENS

e.g., Telemetry or GPS

Ethernet 100BaseTX

2

Laptrigger input

1

Configuration via RaceCon

Over Ethernet or MSA-Box II

CCP-Master, data acquisition from ECU that support CAN Calibration Protocol (CCP_MASTER option)

XCP-Master, data acquisition from ECU that support eXtended Calibration Protocol over UDP or CAN (CCP_MASTER option)



Installation Notes

Inspection services recommended after 220 h or 2 years, no components to replace.

This product may contain open source software. Information about license terms and other obligations is given in the manual.

Ordering Information

Display DDU 11

Order number: F02U.V03.208-03

Software Options

CCP/XCP_MASTER

Order number: F02U.V02.213-01

FULL_LOG_1

Order number: F02U.V02.304-01

FULL_LOG_2

Order number: F02U.V02.305-01

IO_EXTENS

Order number: F02U.V02.205-01

DATA_USB

Order number: F02U.V03.476-01

Accessories

Mating Connector Kit AMP Superseal

Order number: F02U.B01.201-01

Rugged USB flash drive

Order number: F02U.V01.342-03

Connector for USB flash drive on car loom side

Order number: F02U.002.996-01

Adapter cable to PC USB-Port

Order number: F02U.V01.343-01

Upgrades

CCP/XCP_MASTER

Enables CCP/XCP master functionality to request data from foreign devices via CAN/CCP protocol, XCP over Ethernet (UDP) or XCP via CAN.
(ASAP2 file from ECU manufacturer required)

FULL_LOG_1

1,500 channels/1 kHz sampling rate on Recording 1

FULL_LOG_2

4 GB memory on Recording 2

IO_EXTENS

4 x Analog In (5 V/12 bit), Digital In, Wheelspeed HALL or Wheelspeed DF11

1 x Analog In (5 V/12 bit), Digital In or Laptrigger In

Switchable 3.01 kOhm pull-up resistors for all analog inputs

1 x CAN or RS232 (switchable via RaceCon)

DATA_USB

Data copy to USB flash drive

ABSDIAG

Upgrade Onboard Diagnostic Package ABS M5

  • Enables functionality like error memory read and erase, and repair bleed from UIM menu in display

External switch for page selection, 12 steps

B261.209.658-01

External switch for brightness adjustment or page selection, 6 steps

B261.209.659-01
